| Model | BCM-1000A | BCM-1300A | BCM-1600A |
| Cleanliness | ISO CLASS5 | ||
| Air Velocity | 0.33mls±0.03m/s | ||
| Noise | ≤62 dB(A) | ||
| Illumination | 2300 Lx | ||
| Power Supply | AC220V.1φ，50Hz | ||
| Consumption | 500 w | ||
| Weight | 220kg | 250 kg | 270kg |
| Work Dimension (W1XD1XH1) | 1000x700x620 mm 39.4"x27.6"x24.4") | 1300x700x620mm (51.2"x27.6"x24.4") |
1600x700x620 mm (63.0"x27.6"x24.4") |
| Overall Dimension WXDXH) | 1200x780x1800 mm (47.2"x30.7x70.9") | 1500x780×1800 mm (59.1"x30.7"x70.97) | 800x780×1800 mm (70.9”x30.7"x70.9) |
| Size &No.of HEPA Filter (supply) | 915x610×50mmx1set 36.0~x24.0"x2.0"x1set) |
1220x610x69 mmx1set (48.0°x24.0°x2.7"x1set) |
760x610x69mmx2sets (29.9"x24.0"x2.7"x2sets) |
| Size &No.of HEPA Filter (exhaust) | 480×90x50 mmx1set (18.9"x3.5°x2.0"x1set) |
480x150x50 mmx1set (18.9"x5.9"x2.0°x 1set) |
480x200x50 mmx1set (18.9"×7.9"x2.0"x1set) |
| Light | LED7wx2pcs | LED7wx 2pcs | LED7wx2pcs |
| UV Light | 18wx2pcs | 18wx2pcs | 18wx2pcs |
| No.of Colony | ≤0.5cfuldish*0.5h | ||
| Materials | Working table:Al-in-one Stainless Steel,Outside cabinet:high grade steel and lacquered in ivory. | ||
| Mode of Operation | single people/double side | double people/double side | double people/double side |
